Floating Point Binary

IEEE 754 — The Universal Standard

IEEE 754 is the technical standard for floating point arithmetic used by virtually every modern CPU, GPU, and programming language. It defines how real numbers are represented in binary, how arithmetic operations behave, and how exceptional conditions (division by zero, overflow, invalid operations) are handled. I have worked with it across C, Java, JavaScript, Python, and Rust — the bit layout is always the same.

A floating point number in IEEE 754 consists of three fields packed into a fixed-width binary word:

When I was optimizing a physics simulation, I used the binary representation of floats to implement a fast inverse square root. Reinterpreting the float bits as an integer, subtracting from a magic constant, and shifting gave a surprisingly good approximation.

• Sign (1 bit) — 0 for positive, 1 for negative
• Exponent — biased integer that encodes the power of two scale factor
• Mantissa (significand) — fractional part of the normalized significand

The value is computed as: (-1)^sign * (1 + mantissa) * 2^(exponent - bias)

The leading "1" before the decimal point is implicit — it is not stored. This is called the implicit leading bit trick, and it gives you one extra bit of precision for free. The bias ensures that the stored exponent is always positive, making comparisons easier to implement in hardware.

Float32 (Single Precision): 1 + 8 + 23

A 32-bit float (also called binary32 or single precision) uses 1 bit for the sign, 8 bits for the exponent, and 23 bits for the mantissa. The exponent bias is 127. This format can represent values from approximately 1.4e-45 to 3.4e38, with about 7 decimal digits of precision.

Float32 bit layout:
 31 | 30:23 | 22:0
Sign|Exponent|Mantissa
  0 |01111100|01000000000000000000000

Bit positions:
  [31]       Sign
  [30-23]    Exponent (8 bits, bias = 127)
  [22-0]     Mantissa (23 bits, implicit leading 1)

# Example: converting 5.75 to IEEE 754 float32
# Step 1: Convert to binary
5 = 101 (binary)
0.75 = 0.11 (binary: 0.5 + 0.25)
5.75 = 101.11

# Step 2: Normalize to 1.xxxx * 2^n
101.11 = 1.0111 * 2^2

# Step 3: Extract fields
Sign = 0 (positive)
Exponent = 2 + 127 = 129 = 10000001
Mantissa = 01110000000000000000000 (fractional part only, drop the leading 1)

# Result: 0 10000001 01110000000000000000000
# Hex:  0x40B80000

Let me decode a float from its hex representation to verify the math:

// Decode 0x40B80000 back to decimal
int bits = 0x40B80000;

int sign     = (bits >> 31) & 1;       // 0
int exponent = (bits >> 23) & 0xFF;   // 129
int mantissa = bits & 0x7FFFFF;        // 0x380000

// Reconstruct the value
int realExponent = exponent - 127;     // 2
double value = Math.pow(-1, sign)
             * (1 + mantissa / Math.pow(2, 23))
             * Math.pow(2, realExponent);
// value = 5.75 ✓

Float64 (Double Precision): 1 + 11 + 52

A 64-bit double (binary64 or double precision) uses 1 bit for the sign, 11 bits for the exponent, and 52 bits for the mantissa, with a bias of 1023. This gives about 15-17 decimal digits of precision and a range from 5e-324 to 1.8e308.

Float64 bit layout:
 63 | 62:52 | 51:0
Sign|Exponent|Mantissa
  0 |10000000001|1000000000000000000000000000000000000000000000000000

# Example: converting 12.25 to IEEE 754 float64
12.25 in binary = 1100.01
Normalized: 1.10001 * 2^3

Sign = 0 (positive)
Exponent = 3 + 1023 = 1026 = 10000000010
Mantissa = 1000100000000000000000000000000000000000000000000000

# Result: 0 10000000010 1000100000000000000000000000000000000000000000000000

# In JavaScript (which uses float64 for all numbers):
const view = new DataView(new ArrayBuffer(8));
view.setFloat64(0, 12.25);
const high = view.getUint32(0);   // 0x40288000
const low  = view.getUint32(4);   // 0x00000000

I learned the hard way that JavaScript's Number is always IEEE 754 float64. There is no integer type — every number is a double. This means integers up to 2^53 (about 9 quadrillion) are represented exactly, but beyond that, precision loss occurs. If you are doing bit operations on large integers in JS, our 64-bit programmer calculator uses BigInt to avoid this trap.

Special Values: NaN, Infinity, Denormals

The IEEE 754 standard reserves certain exponent values to represent special cases. Understanding these is critical for writing robust numerical code — I have debugged production issues where a NaN silently propagated through a calculation and corrupted downstream results.

Denormalized numbers (or subnormals) fill the underflow gap between zero and the smallest normal number. Instead of the implicit leading 1, denormals have a leading 0, sacrificing precision to represent very small values. They are much slower on most CPUs because they require microcode assistance — if you care about performance and know you will never need subnormals, many CPUs let you flush them to zero.

// Checking for special float values (C)
#include <math.h>
float x = some_value;

if (isnan(x))  { /* not a number */ }
if (isinf(x))  { /* positive or negative infinity */ }
if (isnormal(x)) { /* normal (not zero, subnormal, inf, or nan) */ }

// In Java:
float x = some_value;
if (Float.isNaN(x))      { /* NaN */ }
if (Float.isInfinite(x)) { /* infinity */ }
if (Float.isFinite(x))   { /* finite (not NaN and not infinity) */ }

// NaN is never equal to itself — this is by design in IEEE 754
float nan = Float.NaN;
System.out.println(nan == nan);  // false!
System.out.println(nan != nan);  // true!

The fact that NaN is never equal to itself is a deliberate IEEE 754 design choice. It enables consistent behavior across expressions like 0.0 / 0.0, sqrt(-1.0), and infinity - infinity. In Java, the Float.NaN != Float.NaN expression evaluates to true, which is unusual for a comparison but mathematically correct for NaN propagation.

Precision Gotchas — Why You Cannot Trust Floating Point

The classic example that confuses every programmer at some point: 0.1 + 0.2 != 0.3. This is not a bug in any language — it is a fundamental property of binary floating point representation.

# In Python (IEEE 754 double precision):
0.1 + 0.2  # 0.30000000000000004
0.1 + 0.2 == 0.3  # False

# In JavaScript (also IEEE 754 double precision):
0.1 + 0.2  // 0.30000000000000004

# In C:
float a = 0.1f;
float b = 0.2f;
printf("%.10f\n", a + b);  // 0.3000000119 (different rounding in float vs double!)

The reason: in binary, 0.1 is a repeating fraction, just like 1/3 is in decimal. The binary representation of 0.1 is 0.00011001100110011... repeating forever. Since IEEE 754 can only store a finite mantissa (23 bits for float, 52 for double), the value is rounded. Adding two rounded values gives a result that is slightly off from the mathematically exact answer.

Here are the practical rules I follow to avoid floating point surprises in production code:

// Rule 1: Never compare floats for equality directly
// Wrong
if (a + b == 0.3) { ... }

// Right — use an epsilon comparison
const double EPSILON = 1e-9;
if (fabs((a + b) - 0.3) < EPSILON) { ... }

// Rule 2: Use integer arithmetic for money
// Wrong
double price = 19.99;
double tax = price * 0.08;  // 1.5992... might round wrong

// Right
int cents = 1999;
int taxCents = cents * 8 / 100;  // integer arithmetic, exact

// Rule 3: Prefer double over float unless memory is critical
// float has ~7 digits of precision; double has ~15-17
// In Java and JavaScript, float is less common — stick with double
