What is the difference between signed and unsigned integers?

A signed integer can represent negative and positive numbers using two's complement encoding. An 8-bit signed integer ranges from -128 to 127. An unsigned integer represents only non-negative values, so an 8-bit unsigned integer ranges from 0 to 255. The bit pattern 0b11111111 means 255 in unsigned but -1 in signed.

How does two's complement work?

In two's complement, negative numbers are encoded by inverting all bits and adding 1. For example, to represent -5 in 8 bits: start with 5 (00000101), invert all bits (11111010), add 1 (11111011). The most significant bit acts as the sign bit: 0 for positive, 1 for negative.

When should I use unsigned integers in C?

Use unsigned integers for: bit manipulation (flags, masks, bit fields), array indices and sizes (size_t), values that cannot logically be negative (counters, lengths), hardware registers, and when you need the extra range (0-255 vs -128 to 127). Avoid unsigned for values used in subtraction or comparison with signed types to prevent subtle bugs.

Developer looking at code with binary numbers on screen, signed vs unsigned integers explained

Signed vs Unsigned Integers: The Bit-Level Difference

The bit pattern 11111111 — eight ones. What number does it represent? If you answer 255, you are assuming unsigned. If you answer -1, you are assuming signed with two's complement. Both are correct, depending on context. The bits do not change. Only the interpretation does.

This distinction is responsible for some of the most frustrating bugs in C: sign extension surprises, unsigned wraparound in loops, and mixed signed/unsigned comparisons that defy intuition. Here is how it works at the bit level.

Unsigned Integers: Pure Binary Counting

An unsigned integer is straightforward: each bit contributes its positional value. Bit 0 adds 1, bit 1 adds 2, bit 2 adds 4, and so on. An N-bit unsigned integer ranges from 0 to 2^N - 1.

Bit Pattern (8-bit)	Unsigned Value	Hex
00000000	0	0x00
00000001	1	0x01
01111111	127	0x7F
10000000	128	0x80
11111110	254	0xFE
11111111	255	0xFF

Use unsigned when your value cannot be negative: array indices, bitmasks, counters, sizes, hash values, memory addresses.

Signed Integers: Two's Complement

Two's complement is the universal standard for signed integers. Every modern CPU uses it. The most significant bit (MSB) acts as the sign bit: 0 means positive (or zero), 1 means negative.

Bit Pattern (8-bit)	Signed Value	Why
00000000	0	Zero is zero
00000001	1	Standard binary
01111111	127	Largest positive (2^7 - 1)
10000000	-128	Smallest negative (-2^7)
11111110	-2	Invert: 00000001, +1 = 2 → -2
11111111	-1	Invert: 00000000, +1 = 1 → -1

To negate a number in two's complement: invert all bits and add 1. To find the value of a negative bit pattern: same process, same result.

// Negate 5 (00000101) in 8-bit two's complement:
// Invert: 11111010
// Add 1:  11111011  ← this is -5

// Decode 11111011 (what signed value is this?):
// MSB is 1 → negative
// Invert: 00000100
// Add 1:  00000101 → value is 5 → so pattern represents -5

Sign Extension: The Silent Bug Creator

When you assign a smaller signed type to a larger signed type, the compiler sign-extends: it copies the sign bit into all the new upper bits. This preserves the numeric value but changes the bit pattern.

int8_t  small = -1;      // 0xFF (11111111)
int16_t large  = small;   // 0xFFFF (sign-extended — still -1)
uint16_t ul    = small;   // 0xFFFF (same bits) but interpreted as 65535!

// This is the bug:
if (ul > 1000)
    printf("ul is huge: %u\n", ul);  // Prints 65535 — surprising!

Unsigned Wraparound vs Signed Overflow

Unsigned overflow is defined behavior in C — it wraps around modulo 2^N. Signed overflow is undefined behavior — the compiler can assume it never happens and optimize accordingly.

// Unsigned wraparound (defined — always works)
uint8_t u = 255;
u = u + 1;    // u becomes 0 (wraps around)

// Signed overflow (undefined behavior — nasal demons)
int8_t s = 127;
s = s + 1;    // UNDEFINED! Compiler can do anything

This is why for (unsigned i = n; i >= 0; i--) is an infinite loop — unsigned can never be negative. The condition i >= 0 is always true.

C Type Ranges at a Glance

C Type	Bits	Signed Range	Unsigned Range
char / unsigned char	8	-128..127	0..255
short / unsigned short	16	-32768..32767	0..65535
int / unsigned int	32	±2.1 billion	0..4.3 billion
long long	64	±9.2×10^18	0..1.8×10^19

Rules of Thumb

Use unsigned for bitmasks, flags, sizes, and anything that interacts with bitwise operators
Use signed for arithmetic values that can go negative
Avoid mixing signed and unsigned in comparisons — the implicit conversion rules in C are surprising
Use uint32_t / int32_t from <stdint.h> when you need exact widths
Enable compiler warnings: -Wsign-conversion -Wsign-compare
